EPT.PELM.30

• • Tonnage, kg.: 15.000 кг
  • Overall dimensions, length х width х height mm.: 3.500 х 2.500 х 600 (450)
  • Length of telescopic hitch mechanism, mm.: 3.000 – 5.500
  • Curb weight, kg.: 3.500 – 4.200
  • Diameter of towing ring of hitch mechanism, mm.: 77
  • Suspension: The front wheels are controlled by the traction mechanism of the coupling device, the rear wheels are stationary. Axle/bearing suspension, blind type (thermally pressed).
  • Busbar: Double-tire wheel, solid wheels of wear-resistant rubber.
  • Working temperature range, °С.: from -60 to +60
  • Warranty , months: 120
  • Warranty operating life, months: 2240

EPT.PELM.50

• • Tonnage, kg.: 30.000 кг
  • Overall dimensions, length х width х height mm.: 6.000 х 3.850 х 800 (600)
  • Length of telescopic hitch mechanism, mm.: 4.800 – 5.900
  • Curb weight, kg.: 9.850 – 12.300
  • Diameter of towing ring of hitch mechanism, mm.: 77
  • Suspension: The front wheels are controlled by the traction mechanism of the coupling device, the rear wheels are stationary. Axle/bearing suspension, blind type (thermally pressed).
  • Busbar: Double-tire wheel, solid wheels of wear-resistant rubber.
  • Working temperature range, °С.: from -60 to +60
  • Warranty , months: 120
  • Warranty operating life, months: 2240

EPT.PELM.90

• • Tonnage, kg.: 90.000 кг
  • Overall dimensions, length х width х height mm.: 6.280 х 4.000 х 800 (600)
  • Length of telescopic hitch mechanism, mm.: 4.800 – 6.280
  • Curb weight, kg.: 14.500 – 16.890
  • Diameter of towing ring of hitch mechanism, mm.: 77
  • Suspension: The front wheels are controlled by the traction mechanism of the coupling device, the rear wheels are stationary. Axle/bearing suspension, blind type (thermally pressed).
  • Busbar: Double-tire wheel, solid wheels of wear-resistant rubber.
  • Working temperature range, °С.: from -60 to +60
  • Warranty , months: 120
  • Warranty operating life, months: 2240
